Funnelets 0.036" I.D. 100 pack | Part#2000-0230P100

(0)
Write review
 In stock
Call for Price
Product Overview
Delivery and returns
  • Model
  • 2000-0230P100

Description:

PCB Repair Funnelets

Funnelets 0.036" ID – 100 Pack

Funnelets with a minimum inner diameter of 0.036 inch, supplied in an approximate 100-pack. APE part number 2000-0230P100.

Part #2000-0230P100  |  0.036 in ID  |  Approx. Qty. 100

Funnelets 0.036-inch ID, APE part 2000-0230P100, 100 pack

Product Overview

This approximate 100-pack contains FUNNELET-style funnelets with a 0.047-inch outside diameter and a minimum inner diameter of 0.036 inch. Listed board thickness is 0.031 inch (0.787 mm), 1/32 inch.

Quantity note: Counts of eyelets and funnelets are approximate, determined by scale, with a tolerance of ±3 pieces.

Product Details

  • ✓ Minimum inner diameter: 0.036" (0.9144 mm)
  • ✓ Outside diameter: 0.047" (1.193 mm)
  • ✓ Range style: FUNNELET
  • ✓ Approximate 100-pack (±3 pieces)

Product Specifications

Product Funnelets 0.036" ID
APE Part Number 2000-0230P100
Outside Diameter 0.047" (1.193 mm)
Length Under Flange 0.062" (1.5748 mm)
Flange Diameter at Pierce 0.080" (2.032 mm)
Minimum Inner Diameter 0.036" (0.9144 mm)
Range Style FUNNELET
Board Thickness 0.031" (0.787 mm), 1/32"
Package Quantity Approximately 100; scale-counted, ±3 pieces
PACE Part Number 1347-0007
Motorola Part Number 0580384F08

Need help confirming compatibility?

Contact APE to confirm the correct funnelet size for your circuit board repair application.
