Funnelets 0.036" I.D 25 pack | Part#2000-0058P25

(0)
Write review
 In stock
$27.50
Product Overview
Delivery and returns
  • Model
  • 2000-0058P25

Description:

PCB Repair Funnelets

Funnelets 0.036" ID – 25 Pack

Funnelets with a minimum inner diameter of 0.036 inch, supplied in an approximate 25-pack. APE part number 2000-0058P25.

Part #2000-0058P25  |  0.036 in ID  |  Approx. Qty. 25

Funnelets 0.036-inch ID, APE part 2000-0058P25, 25 pack

Product Overview

This approximate 25-pack contains FUNNELET-style funnelets with a 0.047-inch outside diameter and a minimum inner diameter of 0.036 inch. Listed board thickness is 0.046 inch (1.168 mm), 3/64 inch.

Quantity note: Counts of eyelets and funnelets are approximate, determined by scale, with a tolerance of ±3 pieces.

Product Details

  • ✓ Minimum inner diameter: 0.036" (0.9144 mm)
  • ✓ Outside diameter: 0.047" (1.193 mm)
  • ✓ Range style: FUNNELET
  • ✓ Approximate 25-pack (±3 pieces)

Product Specifications

Product Funnelets 0.036" ID
APE Part Number 2000-0058P25
Outside Diameter 0.047" (1.193 mm)
Length Under Flange 0.085" (2.159 mm)
Flange Diameter at Pierce 0.072" (1.8288 mm)
Minimum Inner Diameter 0.036" (0.9144 mm)
Range Style FUNNELET
Board Thickness 0.046" (1.168 mm), 3/64"
Package Quantity Approximately 25; scale-counted, ±3 pieces

Need help confirming compatibility?

Contact APE to confirm the correct funnelet size for your circuit board repair application.

Call 800-822-8646
